Blackmagic announces new ATEM 4 M/E Constellation 4K: 40 x 12G SDI inputs

Blackmagic announces new ATEM 4 M/E Constellation 4K: 40 x 12G SDI inputs

[12:20 Sun,30.April 2023   by ]

Blackmagic announced the ATEM 4 M/E Constellation 4K, a new Ultra HD model for its ATEM Constellation family of mixers, at NAB 2023. The ATEM 4 M/E Constellation 4K is equipped with 40 scalable 12G-SDI inputs and supports video standards up to Ultra HD 2160p/60. Its features are similar to those of the ATEM 4 M/E Constellation HD; in addition, the new 4K model offers 24 x 12G-SDI aux outputs, 16 upstream ATEM Advanced Chroma Keyers, four downstream keyers, four Ultra HD media players, two SuperSource multilevel processors and more.

atem-4me-constellation-4k-hero
Blackmagic ATEM 4 M/E Constellation 4K





ATEM Constellation Mixer

.
Blackamgic&s ATEM Constellation mixers come in a compact rackmount design with an integrated control panel, and feature an integrated display on which program output is shown and on-screen menus for changing mixer settings. Functions such as the keyer, media loading and fade can be controlled directly from the front panel. At the rear of the mixer are 3G-SDI- 12G-SDI inputs, aux outputs, and connectors for balanced audio and Ethernet for control. RS-422 ports for serial control and MADI ports for digital audio are also provided on the two 4-M/E models.

ATEM Constellation mixers are designed for use at concerts, live sporting events and music festivals, for example, when the action is captured by multiple cameras from different perspectives. Compositing with multiple layers can be created using the four DVE processors.

atem-4me-constellation-4k-rear
Blackmagic ATEM 4 M/E Constellation 4K


Mixers of the ATEM Constellation family are equipped with a different number of independent outputs depending on the model. It is possible to independently route any SDI input or internal source to any SDI output e.g. to route separate feeds to stage screens, master recorders or streaming processors. All SDI outputs include the signals for program audio, RP-188 timecode, SDI camera control, tally and talkback.

For live streaming, the USB-C port on an ATEM Constellation acts as an ordinary 1080p webcam to any streaming software for maximum complete compatibility, when in fact it is a live production mixer.

atem-4me-constellation-4k-angle
Blackmagic ATEM 4 M/E Constellation 4K


The mixer&s internal multiviewer is used to monitor multiple sources on a single screen. ATEM 4 M/E Constellation are equipped with four independent multiviewers. All external SDI inputs and all internal sources can be assigned to any windows. Each multiviewer can be set up for 4, 7, 10, 13 or 16 simultaneous views respectively. Tally borders, source labels and VU meters can be displayed as overlays in each view. The red or green tally border of each view represents at a glance which sources are currently on air.

Main features of the ATEM 4 M/E Constellation 4K

.
- Advanced design with built-in front panel controls
- Impressive 40 scalable 12G-SDI inputs
- 24 arbitrarily assignable 12G-SDI outputs
- USB output acts as a webcam and supports any video software
- Four independent multiviewers with different layout options
- Four independent DVE processors
- Professional talkback compatible with ClearCom and RTS
- Internal media storage for stills and motion graphics
- With 16 ATEM Advanced Chroma Keyers
- Two SuperSource multilevel processors
- Multirate 12G-SDI for all HD and Ultra HD television standards up to 2160p/60
- Integrated 156-channel Fairlight audio mixer
- Compatible with all ATEM hardware control panels

Availability and Price


Available worldwide, the ATEM 4 M/E Constellation 4K will be available in June at a price of ,995.

Link more infos at bei www.blackmagicdesign.com
