Blackmagic ATEM Television Studio HD8: New all-in-one live production mixer

Blackmagic ATEM Television Studio HD8: New all-in-one live production mixer

[16:54 Fri,24.February 2023   by ]

Blackmagic Design has introduced the new Blackmagic Studio Camera 6K LINK, as well as two new ATEM Television Studio HD8 models and the ATEM Microphone Converter. With the two ATEM Television Studio HD8 models, Blackmagic is launching a new family of professional all-in-one live production mixers that combine broadcast features in a compact and portable design complete with an integrated control panel. They are intended for use in small venues and OB vans where there is no space for broadcast racks.

Blackmagic ATEM Television Studio HD8

The mixers offer eight scalable SDI inputs, two aux outputs, four ATEM Advanced Chroma Keyers, two downstream keyers, SuperSource, two media players, DVE, and numerous transitions. They offer features such as live hardware streaming, recording, Fairlight audio mixer, talkback, still graphics storage, multiview, and optional internal cloud storage. The ISO model also records all 8 input signals for later editing.


Using the eight 3G-SDI video inputs, multiple cameras such as the Blackmagic Studio Camera or Blackmagic URSA Broadcast G2 can be connected for different perspectives of an event. All 1080HD or 720HD video sources, regardless of their video standards, are resynchronized to match the mixer&s video standard.

Separate program return feeds can be sent to all cameras via the nine 3G-SDI program outputs for tally, talkback and camera control signals. Two aux outputs are also provided for operating stage monitors and master recorders. For monitoring the cameras via multiview on an external monitor, there is a dedicated 3G-SDI and an HDMI output. Using the multiview function, all video inputs, preview and program can be displayed on a single monitor. In addition, each view provides custom identifiers and audio level meters.

Blackmagic ATEM Television Studio HD8 Interfaces

An ATEM Television Studio HD connected to a PC via USB is recognized by the PC as a webcam and can thus be used as a 1080HD video source in any corresponding program. With the help of the integrated hardware streaming engine, it is also possible to stream directly from the ATEM Television Studio HD live via Ethernet to the network, for example to YouTube, Facebook and Twitch.

The integrated Fairlight audio mixer allows live audio mixing, it has enough channels for all SDI inputs as well as extra channels for the XLR, RCA and MADI inputs. Each input channel has 6-band parametric EQ as well as compressor, limiter, expander, noise gate and full pan control.

Operation via panel or software

Most functions are accessed via the control panel or, alternatively, via the free ATEM Software Control operating software (macOS/Windows) - the latter offering even more features such as live mixing, audio mixing, in-camera grading and media management, and the creation and execution of complex macros. Control panel buttons are used to select sources, trigger transitions, and configure video effects. Audio mixer control and a dedicated display for live control are also integrated. There is also an iris lever for manual control of transitions. A choice of SMPTE wipes is available, as well as DVEs that move across the screen to off during transitions between sources.

Blackmagic ATEM Television Studio HD8 Control Software


ATEM Television Studio HD models support recording to external USB drives as well as optional internal M.2 storage. The internal storage and all external USB drives are shared over the local Ethernet network so they can be accessed by the team. Recording is in H.264 format with AAC audio. A new recording can be appended directly to a previous one via "Append" mode.

ATEM Television Studio HD8 ISO

The ATEM Television Studio HD ISO model records all input signals in eight separate files synchronized by timecode, plus a master video file, allowing post-processing of live events. In addition, a DaVinci Resolve project file is linked to the video input files and saved. When this is opened in Resolve, the live production is available as an edit timeline.

In addition to camera control and tally, the ATEM Television Studio HD ISO model allows connection of remote cameras such as the Blackmagic URSA Broadcast G2, Blackmagic Studio Camera 4K Pro G2 or Blackmagic Studio Camera 6K Pro cameras, which can send the live stream in H.264 directly to the mixer.

Blackmagic ATEM Television Studio HD8

Features of the ATEM Television Studio HD8

- All-in-one mixer with control panel
- Connectivity for up to eight SDI cameras
- Wide range of professional video effects included
- Internal media storage for stills and motion graphics
- Four ATEM Advanced Chroma Keyers for projects with green or blue screens
- SuperSource multilevel processor with four DVEs included
- Eight scalable 3G-SDI inputs
- Nine 3G-SDI outputs for program video and two 3G-SDI aux outputs
- Audio mixer supports limiter, compressor, 6-band EQ and more
- Multiview feature with 16 views to monitor all cameras on a single monitor
- Live streaming via Ethernet or using cell phones via USB
- Recording to USB drives or optional cloud storage via internal memory
- USB output acts as webcam and supports any video software
- ISO model supports recording from all video inputs for post production editing
- ISO model records DaVinci Resolve project files
- ISO model supports remote cameras over the Internet
- Includes free ATEM software control application for Mac and Windows
- Localized into 13 popular languages
- ATEM Microphone Converter provides additional audio inputs

ATEM Microphone Converter

ATEM Microphone Converter

For special applications such as podcast studios that require additional microphones, Blackmagic has developed the new ATEM Microphone Converter, which extends the audio inputs of ATEM Television Studio models via MADI. It connects directly to the MADI connector and requires no setup. The ATEM Microphone Converter has four analog inputs switchable between mic and line level, as well as phantom power. Its noise floor is -129 dBV, distortion is 0.002%, and dynamic range is -131 dB(A). Several converters can be connected in series for additional inputs.

ATEM Microphone Converter

Features of the ATEM Microphone Converter

- Expands the number of audio inputs to the Blackmagic ATEM Television Studio HD
- Rugged design in typical converter style
- Connection via MADI supports multi-channel audio
- Extremely low noise floor of -129 dBV
- Ultra-wide dynamic range of 131 dB(A)
- Precise input balance and low distortion of 0.002
- HDMI monitoring with tracking audio waveform display included

Availability and Price

The ATEM Television Studio HD8 models are available now at a price of around €3,500 or €3,900 for the ISO model. The ATEM Microphone Converter will cost around 470 euros and should be available in the second quarter.
